Easily automate your water meter with Homewizard

This is a topic that will interest more than one, but be careful it will not be a miracle! but I propose you a new module manufactured by a Dutch company Homewizard, the watermeter HWE-WTR-23. It is a product that works in wifi and that records the water consumption thanks to a magnetic receiver. It is not a big novelty especially since Pieter Brinckman has already made a Diy module based on esp32 which will cost you less.

Watermeter HWE-WTR-23

By Homewizard

Instantaneous water consumption measurement, Wi-Fi connection, adaptable to water meters on the European market and all compatible with Home Assistant

49.95€

Buy Now

Super strong Homewizard HWE-WTR-23 packaging.

Unpacking

The packaging is very well done, the outer carton is resistant in short you will not encounter any problems during delivery. Inside we will find a set of:

• screws
• 3 adapters for different brands of meters
• an installation guide especially on meters
• a usb-c socket
• ​​a 3 meter usb cable
• and of course a reading module HWE-WTR-23

Good to know

• On mains the Homewizardd watermeter HWE-WTR-23 reads data instantly.
• On Battery The Homewizard watermeter module HWE-WTR-23 reads data 4 times a day.

Held in the hand, so you can see the dimensions of the module, and you will find an access hatch for the connection by 123A batteries

Amazon Basics CR123A

By Amazon

CR123A lithium batteries ideal for home automation devices and photos

Buy Now out of Amazon

Below are some pictures of the HWE-WTR-23 to give you an idea of ​​the product, it remains basic and does the essentials.

I would like to congratulate Homewizard for providing a 4 meter long USB-C cable.

The Homewizard watermeter HWE-WTR-23 costs a little less than €50 but it is compatible with all European meters thanks to the adapters provided with it and that is a real plus.

Installation of the Homewizard HWE-WTR-23

Homewizard HWE-WTR-23 and Remote Reading

Well I won’t hide it from you, this type of product has a big drawback, it can only be installed on a meter without a pulse transmitter. Yes, pulse meters are installed and work with magnetic transmitters/receivers.

If you wish, you can easily remove the pulse meter; for me it’s an itron.

On the other hand, this one reads continuously, removing it and turning the water meter will create a difference, and the day the water company changes the pulse transmitter, they will take a manual reading of the meter and the bill could be steep.

Some time ago, I wrote a procedure to measure water consumption on an Itron everblu cyble transmitter, using a 433mHz receiver, good reading.

Domotize the Itron water meter with esp and cc1101 in ha for 10€

Setting up the HWE-WTR-23

There again nothing more to say, the installation was carried out without any problems, just follow the instructions.

Finally, you just have to clip the module onto the adapter and that’s it.

From there, all you have to do is connect the HWE-WTR-23 to your home’s Wi-Fi network and calibrate the whole thing

Which meters are compatible

The list is long and that’s great, find the maximum amount of information below.

• Zenner
• Sensus
• Itron
• Actaris,
• Hidroconta
• Schlumberger
• Elster
• Honeywell
• Maddalena MVM
• DH Metering and Diehl Metering in 2 minutes. Just insert the water meter into the adapter, connect it to Wi-Fi and that’s it.

	Zenner Zenner water meters are compatible. Simply attach bracket 2 and two screws (PS4/16).
	Sensus (1) There are two separate Sensus meters with different mountings. Check the Sensus meter you have carefully to ensure that the bracket is properly secured. Sensus (1) water meters are compatible and are secured using bracket 2 and two screws (PS2.6/8).
	Sensus (2) Check the Sensus meter in your possession carefully, so that you can fix the bracket properly. The Sensus (2) water meters are compatible and are fixed using bracket 1 and two screws (PS2.6/8). If the cover of this Sensus water meter is in the way when installing the bracket, you can turn the inside of the water meter (it is separate from the outer casing).
	Itron, Actaris, Hidroconta and Schlumberger Most meters have a cap on the tip of the screw that can be broken off. Refer to the image for an example of the three different caps. This water meter can also be black or blue. Itron, Actaris, Hidroconta and Schlumberger water meters are compatible and are secured using bracket 1 and a screw (M4/12).
	Itron, Actaris, Hidroconta et Schlumberger
	Elsther, Honeywell Elster and Honeywell water meters are compatible and are fixed using bracket 1 and two screws (PS4/16).
	Diehl Metering Diehl Metering water meters do not have screw holes, instead you can snap the bracket 3 into the water meter.
	Dh Metering DH Metering water meters are compatible and are fixed using bracket 2 and two screws (M2.5/12).
	Maddalena MVM On Maddalena MVM water meters, the bracket must be placed upside down. You must hook the bracket on the left side of the water meter and screw it on the right side (with a screw, P2.6/8). Make sure that your analogue water meter has this option.

Watermeter HWE-WTR-23

By Homewizard

Instantaneous water consumption measurement, Wi-Fi connection, adaptable to water meters on the European market and all compatible with Home Assistant

49.95€

Buy Now

Installation video HWE-WTR-23

Official installation video

First settings via the official application

If you want to download the Homewizard application for Apple or Android, no worries, you just have to scan the Qrcode below.

More informations on Qrcode

This QRcode allows you to download the Homewizard app directly for Android or Apple you have the choice between scanning this QRcode from your smartphone or clicking directly on the link below.

---

Homewizard Apps for Smartphone

Below I made an animated gif of the first connection to the Official application, through the wifi settings, and finally the calibration of the module.

After creating the account, follow the steps, nothing complicated:

• connect the smartphone to the module via the WatermeterSetup connection with the Setuppass code
• then switch to home wifi
• press the button to pair the module
• updates are done immediately if necessary
• finally perform a calibration
• option 1: you can add a rate per m3
• option 2: Homewizard offers an energy+ subscription for 0.99€/month which is useless if you go through Home Assistant

At this point the installation should be operational.

Let’s integrate the HWE-WTR-23 into Home Assistant

More than a year ago Homewizard officially announced its collaboration with Home Assistant by providing a near-perfect integration of its modules, and this is good news.

Homewizard officially announces support for its products in Home Assistant what good news!

API activation and functions

First step: in order to integrate Homewizard products into home assistant, you will first need to activate the API in the Homewizard Smartphone application, to do this go to: cogwheels > Meters > Click on the water meter > Meter settings and activate.

Then in homeassistant you will just have to go to the devices and services tab and in the discoveries you will have Homewizard, Magical 🎉

As a reminder, don’t forget to activate the API function in the Homewizard application, otherwise you will be unable to associate the products with Home Assistant.

Available functions

1. total reading of water consumption (by default in m3 I transformed into liters but the value in the official application remains in m3)
2. instantaneous reading of water consumption per minute
3. Allows you to choose to send consumption information to the cloud or to operate the premises completely, TOP.

Overview in operation

After a few hours of operation on mains power, I made an animated gif of the readings in home assistant, it’s more meaningful

Consumption monitoring, especially integration into the home assistant energy dashboard is compatible so you can monitor consumption on a graph, and you can set a rate.

Very interesting pure local function

HomeWizard allows you to configure the operation of the watermeter HWE-WTR-23 in cloud mode or in pure local, the image below shows you in parallel with the smartphone application when the cloud connection is activated.

Once deactivated you will be able to see that no more data is sent to the Homewizard application so you will be able to use the Homewizard watermeter (measuring water consumption) HWE-WTR-23 completely LOCALLY!!

Official Online Notice

Finally, you can find below the link to the complete online notice of the Homewizard watermeter HWE-WTR-23

Official Homewizard Watermeter Notice

Technical characteristics of the HWE-WTR-23

Product advantages:

• Design
• Versatility
• Ease of installation
• Price (less than €50)
• Long 3m USB-C cable
• Connectivity (mains or batteries)
• Well-made Smartphone application
• Calibration via the Smartphone application
• LOCAL operation option

Product disadvantages:

• Cannot be used on meters with the remote reading function

Watermeter HWE-WTR-23

By Homewizard

Instantaneous water consumption measurement, Wi-Fi connection, adaptable to water meters on the European market and all compatible with Home Assistant

49.95€

Buy Now

Conclusion

Homewizard, a Dutch company, has signed a versatile product that will allow you to accurately measure your water consumption the HWE-WTR-23 is very easy to install the integration into Home Assistant is perfect and this thanks to an agreement between the two companies, the fact of being able to plug into the mains or battery is a big plus. In short, if you want to automate your water consumption with great precision and all easily and if your meter is not equipped with a telemetric transmitter/receiver then this product is for you. It is almost flawless.

I remove 0.2 points for the fact that it cannot be used at the same time as a remote reading transmitter.
